Jupiter Image 2003/01/03(UT)

Clay Sherrod,Damian Peach,Eric Ng,Christophe Pellier

Clay,D.Peach,Eric,Christophe


Dr. P. Clay Sherrod (310mm Schmidt Olympus C-3000 camera)
Some nice views of the areas in and around the GRS; note particularly the
STC white spots and their interactions as well as the SEB fol. the
GRS....there is some nice interaction of the SEBs. and the following "point"
of the GRS.

In my opinion we are at the beginning of a fairly substantial outbreak
within the SEBzone...note in addition to the large open convection activity
a new dark spot that is approaching the CM in the latter image.


Jupiter in steady skies.  Note the northern edge of the GRS and its hollow,
fol. end, and what appears to be a series of small dusky spots which are
overriding the GRS along with the very dark festoon emanating from the s.
edge of the SEB and seemingly merging with the southern perimeter of the GRS
hollow.  Nice spot interaction due So. of GRS as well as throughout STC.
**SEB appears to be in a full-blown disturbance in longitudes fol. the GRS.


Fair conditions;  note the darkening and thickening of the STB in longitudes
fol. the GRS; SEBs festoon on fol. edge of GRS hollow is very pronounced as
is what appears to be a small white spot within the hollow at the following
"point" of the GRS.  STC white spots are well shown as is NEB barge B-4 near
CM.  Note the dark spot that is approaching the CM within the northern part
of the SEBzone.
[Dr. P. Clay Sherrod  Arkansas  State U.S.A]
≪クレイ  シェラード  アメリカ  アーカンサス≫

Damian Peach (11" (28 cm) Celestron SCT SBIG ST-5c camera)
Hi all,

Here are more Jupiter images from last night. Seeing
was again rather mediocre at times, but the webcam
gets around it well.

The area f. the GRS was presented again. Note the
redish colour of the NTBs.

Best Wishes

Damian

----------------------------------------------

JUPITER IMAGES, JANUARY 3rd, 2003.

D. A. Peach, Costa del Silencio, Tenerife, Canary Isl.
11" (28 cm) Celestron SCT @ f/22.1 (0.18"/pixel.)
Philips ToUcam Pro PCVC740K camera.

Total Exposure Times: ~400 -600  x 0.04secs

Seeing fair (p4-7) with frequent turbulent periods.
Transparency good (4.0mag) with high haze/cirrus.
No wind. Light dew.

Equatorial Diam=44.0"
Altitude= 46-67 degs





[Rochester, Kent, UK.]
≪ダミアン−ピーチ  イギリス≫

Eric Ng (10" F6 Newtonian homebuilt reflector : ToUcam Pro)
Dear all,
Attrached link was the Jupiter taken tonight.
Although Hong Kong is affected by the strong
monsoon wind but the seeing was improved while
Jupiter at the zenith.
You can see the GRS and the two Jovian Satellites,
the Io and the Europa.
ou may also see some ovals on the southern polar
region and the group near the central meridian seems
merging together, very interesting.




[Eric Ng, Tai Po site Hong Kong]

Christophe Pellier (180mm Newtonian webcam Toucam Pro)
Hello all, I have obtained color and red ligth images of the planet yesterday.
They span the hemisphere with the SEB outbreak. The original spot looks fainter now, but the Belt following the GRS is very disturbed.
After looking at images of december 2001, I think that the similarity of the evolution of the two events is striking.
The red-ligth images are interesting, although maybe not absolutely conclusive.
Unfortunately the second red image must be misfocused a bit.
Both shows more conspicuous details in some part of the planet, as the blue festoon apparently lying directly into the NEBs (images a and b), or small dark spots on the edge of SEBs (images c and d).








[Christophe Pellier Bruz City , France]
≪クリストフ ペリア フランス≫
