ISS observations Image 2009/09/19(UT)
Ralf Vandebergh,Alfons Diepvens
R.Vandebergh,A.Diepvens
|
Ralf Vandebergh(250mm Newton) |
I'm a bit behind in processing,but this is my latest ISS observation. We see the Progress 34 (M-67)
docked at the aft end of the Russian Zvezda module. First I thought I would miss this Progress which
docked July 29 and undocked Sept 21. The image is taken 2 days before undocking,which means
I captured now 3 Progress supply ships in a row over the last time (P32,P33 and P34).
The image is also taken 2 days after docking of the new Japanese supply ship HTV-1,which is
mounted on the Earth facing side. It's visibility is difficult therefore,but you can recognise it at
the marked position. The HTV-1 leaved the station recently,Oct. 30 and de-orbited and crashed
into the Pacific Ocian on Nov. 1.
We also were lucky with the lighting angle in this capture to have a nice view on the Quest Airlock,
place for astronauts to leave and enter the station for an EVA.
Finally,the Japanese Exposed Facility(JEF) shows good detail. It's mounted on the
Japanese Experiment Module (JEM) or mostly called Kibo.
Imagery: 10inch Newtonian,manually tracked using 6x magnification on the tracking scope.
14 frames taken in good seeing were combined for this capture.
Attached is a close-up version an ISS observation done in September.To give an indication of
proportions of size I have inserted a NASA image of an astronaut at the Quest Joint Airlock,
one of the elements visible in the picture. (For clarity; during my capture there was no
astronaut outside).
However,you can find an image of a spacewalking astronaut on my website:
Image: 10inch Newtonian,manually tracked using a 6x magnifying trackingscope,
composite of 14 frames taken in good seeing)
subject: 2009/09/19 ISS close-up
______________________________________
Attached is a close-up version an ISS observation done in September.To give an indication of
proportions of size I have inserted a NASA image of an astronaut at the Quest Joint Airlock,
one of the elements visible in the picture. (For clarity; during my capture there was no
astronaut outside).
However,you can find an image of a spacewalking astronaut on my website:
http://ralfvandebergh.startje.be/vieuw.php?qid=328303
Image: 10inch Newtonian,manually tracked using a 6x magnifying trackingscope,
composite of 14 frames taken in good seeing)
subject: 2009/09/19 ISS close-up
______________________________________
Attached is a close-up version an ISS observation done in September.To give an indication of
proportions of size I have inserted a NASA image of an astronaut at the Quest Joint Airlock,
one of the elements visible in the picture. (For clarity; during my capture there was no
astronaut outside).
Here is a detail of an image stack taken last September. I regularly imaged the Airlock on the ISS,
but never had such clear view on the Hatch as now. This is the hatch were spacewalking astronauts
[バンディバ:オランダ]
[Ralf Vandebergh:Neighbourhood of Maastricht Netherlands]
|
Alfons Diepvens(200m F9 Apo Refractor) |
ISS space station
19 September 2009
18h58m32s UT
20cm F9 Apo Refractor / Canon 40D in prime focus
1/2500s - 1250 iso
[Alfons Diepvens:Balen Belgium]
