Jupiter Image 2020/05/09(UT)

Clyde Foster,Vincenzo della Vecchia,Anthony Wesley,Tiziano Olivetti,Jose Luis Pereira,Christopher Go
C.Foster,V.della Vecchia,Anthony.W,T.Olivetti,J.Luis,Christopher Go

Clyde Foster
Rather average seeing this morning for the GRS transit.
I spent some time looking at the reddish markings in the GRS wake outbreaks,thinking they may be channel misalignment,but I believe they are real.
There appears to be a methane-bright cloud that may have just passed below the GRS.



[Clyde Foster:Centurion,South Africa]

Vincenzo della Vecchia
Good conditions tonight so I was able to get some quality data.
The NEB is very active,together with the GRS. The red spot on NNTZ is transiting at CM.

[Vincenzo della Vecchia : [Aversa,Italy]

Anthony Wesley
Hi all,here are two images of Jupiter from this morning in reasonable
seeing,the jetstream was a bit kinder this morning and not as fierce.
Data for the colour image was captured between 1751 and 1822 however
there was a gap of about 15 minutes in the middle where the seeing
deteriorated and I didn't record anything.

The IR750 longpass image shows some dark ripples in the white STB.


[Anthony Wesley,Murrumbateman Australia]
≪アンソニ  オーストラリア≫

Tiziano Olivetti
vattached the first images from tonight session,Io shadow is blurred due to the derotation of 4 rgb sets.

attached other images from this morning,the satellite Io and its shadow are visible in the Red channel and blurred in the colour image due to the derotation.
The GRS is rising on the left,and the NEB looks almost destroyed.

[ティジャノ:オリベッティ バンコック タイ]
[Tiziano Olivetti : Bangkok Thailand]

Jose Luis Pereira

[Jose Luis Pereira :Sao Caetano do Sul/Sao Paulo/Brasil]

Christopher Go
Seeing was variable this morning.

The NEB is very active these days.
Note the dark festoons extending up to the NEBn! Red material seem to be clearing at the area just after the CM.
The two white ovals on the NEBn are bright in methane band.  The SEB is still very pale.
Io shadow is starting to bite into the edge of the Jovian disk on the second RGB image.



[Christopher Go : Cebu Philippines]
