Mars - Viking 1 Orbiter
Global mosaic of Hellas and Arabia areas on Mars
Global mosaic of Viking 1 Orbiter images giving an orthographic projection showing the Hellas Planitia
(at lower left of the frame) and Arabia (upper right) regions of Mars.
The mosaic covers the area from -70 to 50 degrees latitude and 260 to 360 degrees longitude.
The images were acquired on 7 July 1980 on orbit 1483 during late northern summer on Mars.
The bright area at the bottom of the image is Hellas Planitia, a large deep basin about 2000 km in diameter.
The bright white coloring is due to carbon dioxide frost in the bottom of the basin, parts of which
are about 8 km lower than the mean planetary surface. The large bright region at the top is Arabia.
Thin white clouds can be seen over the northern (upper) portions of the image.
(Viking 1 Orbiter, MF31S343-483SO)
Location & Time Information
Date/Time (UT): 1980-07-07
Distance/Range (km): 2500.
Central Latitude/Longitude (deg): -10, 320
Orbit(s): 1483
Imaging Information
Area or Feature Type: global view
Instrument: Visual Imaging Subsystem
Instrument Resolution (pixels): 1056 x 1182, 7 bit
Instrument Field of View (deg): 1.54 x 1.69
Filter: N/A
Illumination Incidence Angle (deg): N/A
Phase Angle (deg): N/A
Instrument Look Direction: N/A
Surface Emission Angle (deg): N/A
[NASA/JPL/Space Science Institute]
|
