土星 月惑星研究会 関西支部 （最新）
ALPO-Japan Latest
Saturn Image 2000/10/13(UT)
新川勝仁,池村俊彦,
Damian Peach
M.Niikawa,T.Ikemura,D.Peach
|
Masahito Niikawa (280mm SC, Minolta DimageEx1500 Digital Camera)
|
|
ＧＩＦアニメーション
Saturn on Oct.13, 2000 UT
This animation file consists of;
Frame 1 2000/10/13 16:07:43 (UT) CMI = 133.7, CMIII = 78.5 20 frames composite
Frame 2 2000/10/13 16:19:30 (UT) CMI = 140.6, CMIII = 85.1 21 frames composite
Frame 3 2000/10/13 16:27:15 (UT) CMI = 145.1, CMIII = 89.5 18 frames composite
Frame 4 2000/10/13 16:36:07 (UT) CMI = 150.3, CMIII = 94.5 18 frames composite
Frame 5 2000/10/13 16:45:09 (UT) CMI = 155.6, CMIII = 99.5 16 frames composite
-------------------------------------------------------------
De = -26.4, E.Dia = 19.85"
Telescope : C11 (SC) D=280mm fl=2800mm
Camera :Minolta DimageEx1500 Digital Camera taking lens removed
Effective F No.: 27 (XP24mm Eyepiece Projection)
Filter: R60(600 - 1000nm)
Obs.site : Mozuhonmachi Sakai-City Osaka Japan
Exposure : 1/4 sec
Analog gain:8dB
Image Processing;
* Enhanced with the unsharp masking method.
Seeing = 5/10
Transarency = 3/6
≪大阪府 堺市 新川勝仁≫
|
Toshihiko Ikemura (310mm Newton, NEC PICONA)
|
|
De=-26.4 E.Dia=19.85"
Ring Long dia 45.25" Ring short dia 20.15"
310mm Newtonian(F5) TeleVue barlow 3x(f/24)
NEC PICONA 1/7sec
[T.Ikemura Nagoya Aichi JAPAN]
≪愛知県名古屋市 池村俊彦≫
|
Damian Peach (11" (28 cm) Celestron SCT SBIG ST-5c camera)
|
|
I reprocessed the integrated light Saturn image from Oct 13th for a more
'natural. appearance. What struck me immediately is the presence of the
Keeler gap. I compared the image to Maurizio's Sep 2 shot, and a recent
image by Ed Grafton (both showing the division.) and it is located at
exactly the same place in Ring A. The image is composed of 30 individual
images, so it certainly isnt an artefact!. I also attach an LRGB using the
integrated light image as L component.
[Rochester, Kent, UK.]
≪≪ダミアン−ピーチ イギリス カナリア諸島≫≫
