土星 月惑星研究会 関西支部 （最新）
ALPO-Japan Latest
Saturn Image 2001/11/19(UT)
河原義則,池村俊彦,永長英夫,新川勝仁,Ed Grafton
Y.Kawahara,T.Ikemura,H.Einaga,M.Niikawa,Ed Grafton
|
河原義則 Yoshinori Kawahara (250mm Cassegrain, Digital still camera NEC PICONA)
|
|
変化がないですね seeing:6/10
≪愛知県海部郡弥富町 河原義則≫
|
Toshihiko Ikemura (310mm Newton, Digital still camera NEC PICONA)
|
|
2001/11/19 Saturn images
I found a dark pattern which moves it to EZs with rotation.
It stopped seeing the white small annular belt which
matched in the vicinity the South Pole.
Best wishes,
Toshihiko-Ikemura Japan
Japanese
ＥＺｓに自転に伴って移動する暗い模様を見つけました。
南極付近にあった小さな白いリング状ベルトは見えなくなりました。
≪愛知県名古屋市 池村俊彦≫
|
Hideo Einaga (250mm Newton, Digital Still Camera NEC PICONA)
|
|
2001/11/19 13:28:07 (UT)
CMI = 316.2, CMIII = 115.2
De = -28.5, E.Dia = 20.40"
12 frames composite
Seeing=7/10 Transf=3/5
25cm+balow 3×(F=34)
prism 2deg+Picona(1/7)
HIDEO EINAGA ≪兵庫・加西 永長英夫≫
|
Masahito Niikawa (280mm SC, Digital still camera Minolta DimageEx1500)
|
|
Saturn on Nov.19, 2001
De = -28.5, E.Dia = 20.4"
[R1]
2001/11/19 16:35:55 (UT)
CMI = 66.3, CMIII = 221.0
19 frames composite
[B1]
2001/11/19 16:55:05 (UT)
CMI = 77.6, CMIII = 231.8
18 frames composite
Observer:Masahito Niikawa
Email:zba03198@bird.zero.ad.jp
Obs.site : Mozuhonmachi Sakai-City Osaka Japan
Telescope : C11 (SC) D=280mm fl=2800mm
Camera:Minolta DimageEx1500 Digital Camera taking lens removed
CCD:ICX205AL (Sony Monochrome CCD)
Blue Images
indicate [B]
Filter: B390 (360nm - 500nm)
Exposure :0.5 sec
Effective F No.: 44 (XP24mm Eyepiece Projection)
Near IR Images:
indicate [R]
Filter: R64 (640nm - 1000nm)
Exposure : 0.3 sec
Effective F No.: 44 (XP24mm Eyepiece Projection)
Seeing = 7/10
Transparency = 3/6
Image Processing;
Software binning.
Enhanced with unsharp masking method.
≪大阪府 堺市 新川勝仁≫
|
Ed Grafton (14 inch f/11 Celestron SCT, ST6 CCD medium resolution mode)
|
|
2001/11/19 06:39(UT)
The seeing was excellent with very little to no degradation due to the
atmosphere on most sub-exposures. This image probably represents close to
the limit of what the C14 can do as far as resolution is concerned as the
atmosphere was not really distructive during these exposures. Later the
seeing decayed to about 7/10 when I was shooting Jupiter that same mourning.
This image was processed with non linear filters to enhance the visibility
of the C ring.
Eyepiece Projection @ f/68 w/10mm plossel, projected 70mm, aprox..23 arc seconds per
pixel
Integration Times:
6 BLUE + IR rejection, .6 seconds, Edmunds filters
5 GREEN + IR rejection, .6 seconds, Edmunds filters
4 RED + IR rejection, .6 seconds, Edmunds filters
12 no filter .3 seconds for Luminance
Seeing was excellent 9.5/10. Transparency below average 3-4/10, wind calm,
heavy dew, ground fog present.
[Ed Grafton, Houston Texas]
