土星 月惑星研究会 関西支部 （最新）
ALPO-Japan Latest
Saturn Image 2001/12/07(UT)

永長英夫,池村俊彦,新川勝仁

H.Einaga,T.Ikemura,M.Niikawa

Hideo Einaga (250mm Newton, Digital Still Camera NEC PICONA)
2001/12/07 12:29:26 (UT)
CMI =   1.0, CMIII = 278.2
De = -28.4, E.Dia = 20.47"
7 frames composite
Seeing=4/10 Transf=3/5
25cm+balow 3×(F=30)+prism 2deg+Picona(1/7)
HIDEO EINAGA ≪兵庫・加西　永長英夫≫

Toshihiko Ikemura (310mm Newton, Digital still camera NEC PICONA)











自転に伴って移動する模様は何
も無いようです。

 ≪愛知県名古屋市　池村俊彦≫

Masahito Niikawa (280mm SC, Digital still camera Minolta DimageEx1500)

Saturn on Dec.07, 2001 De = -28.4, E.Dia = 20.5"

[R1] 2001/12/07 14:27:07 (UT)  CMI =  70.0, CMIII = 344.5  30 frames composite

[O1] 2001/12/07 14:54:11 (UT)  CMI =  85.8, CMIII = 359.7  23 frames composite

[O2] 2001/12/07 15:19:18 (UT)  CMI = 100.6, CMIII =  13.8  16 frames composite

[O3] 2001/12/07 15:28:03 (UT)  CMI = 105.7, CMIII =  18.8  23 frames composite

[R2] 2001/12/07 16:16:59 (UT)  CMI = 134.4, CMIII =  46.3  10 frames composite

[B1] 2001/12/07 16:26:21 (UT)  CMI = 139.9, CMIII =  51.6  24 frames composite

[B2] 2001/12/07 16:38:23 (UT)  CMI = 146.9, CMIII =  58.4  18 frames composite

[B3] 2001/12/07 16:50:01 (UT)  CMI = 153.8, CMIII =  64.9  23 frames composite

Observer:Masahito Niikawa
Email:zba03198@bird.zero.ad.jp
Obs.site : Mozuhonmachi Sakai-City Osaka Japan
Telescope : C11 (SC) D=280mm fl=2800mm

Camera:Minolta DimageEx1500 Digital Camera taking lens removed
CCD:ICX205AL (Sony Monochrome CCD)

Blue Images
indicate [B]
Filter: B390 (360nm - 500nm)
Exposure :0.5 sec
Effective F No.: 44 (XP24mm Eyepiece Projection)

Orange Images:
indicate [O]
Filter: O56 with IR Blocker(DR655) (560nm - 660nm)
Exposure : 0.25 sec
Effective F No.: 44 (XP24mm Eyepiece Projection)

Near IR Images:
indicate [R]
Filter: R64 (640nm - 1000nm)
Exposure : 0.3 sec
Effective F No.: 44 (XP24mm Eyepiece Projection)

IR Image:
indicate [IR]
Filter: R64 (640nm - 1000nm)
Exposure : 1.0 sec
Effective F No.: 44 (XP24mm Eyepiece Projection)

Seeing = 6/10
Transparency = 3/6

Image Processing;
Software binning.
Enhanced with unsharp masking method.

Caption:
Please note that the darkness of SEBn and SEBs,
which is darker in shorter wavelength,
it means they are red.
And SEBZ is the most distinguishabe from SEBn and SEBs in Orange images.

説明：
SEBnとSEBsの濃度に注意を払うべきである。それらは、短波長になるほど暗い。
つまり、それらは赤い。
そして、SEBZの、SEBnとSEBsからの識別はオレンジ色で撮った画像において、最も明確になる。

１２月７日の土星観測レポートをお送りします。
南極の小ゾーンはまだ、見えていますが、特に、変化はないようです。
　　≪大阪府　堺市　新川勝仁≫

ALPO-Japan Latest　Saturn Section
