Jupiter Image 2005/03/27(UT)
Christopher Go,Tiziano Olivetti,Brian Colville
Christopher Go,T.Olivetti,B.Colville
Christopher Go (Celestron C8:Toucam webcam)
The GRS and Europa is prominent in this image.



[Christopher Go : Cebu Philippines]
Tiziano Olivetti(180mm Maksutov-Newtonian:Astromeccanica KC381)
2005/03/27 14:25:00 (UT)
CMI=241.7 CMII=128.9 CMIII=159.1 diam.=44.1"
Seeing 3-4/10 transp.8/10
Maksutov Cassegrain 180mm f.eq.=6750 mm and 8000 mm
Colour images: camera Astromeccanica K-SS8H2P IR cut ON
B/W images: Camera b/w Astromeccanica KC381

［ティジャノ:オリベッティ　タイ　バンコク］
[Tiziano Olivetti : Bangkok Metropolis : Thailand]
Brian Colville(300mm F10 Schmidt-Cass:ToUcam Pro)
Telescope:     30cm SCT @ f28
Camera:        ATK-1HS, 320 x 240 mode
Filters:          Luminance - Schuler Clear w/IR Rejection, 45 sec @ 30fps
                        Red - Schuler Red, 45 sec @ 30fps
                        Green - composite from Red/Blue data
                        Blue - Schuler Blue, 60 sec @ 20fps
                        IR - Schuler IR Pass 830nm cut-on, 120 sec @ 5fps
                        Methane - Custom Scientific 889nm, 18nm FWHM, 50 x 3 sec
                        UV - Schuler UV 340nm, 50 x 1 sec
Image Capture via K3CCD Tools
Image Processing via Registax 3.0

[ Brian Colville : Cambray Canada]
