木星 月惑星研究会 関西支部
Jupiter Image 2007/03/03(UT)
阿久津富夫,永長英夫
Christopher Go,Tiziano Olivetti,Robert Heffner,Zac Pujic
Christopher Go,T.Olivetti,T.Akutsu,R.Heffner,Z.Pujic,H.Einaga
|
Christopher Go (Celestron C11) |
The STrD-2 is very prominent in this image. The wake of this disturbance is getting longer. The bluish STB remnant can also be seen setting in this image.
Note the dark red spot under it. There is a large rift on the NEB after the CM. Note also the NEBn below the rift upto the CM. There seems to be a disturbance there.
[Christopher Go : Cebu Philippines]
|
Tiziano Olivetti((275mm Newtonian) |
Poor seeing and transparency this morning. The STrD2 is visibile on the right.
Clear skies
［ティジャノ:オリベッティ タイ バンコク］
[Tiziano Olivetti : Bangkok Metropolis : Thailand]
|
Tomio Akutsu (280mmSC C11) |
3月3日の夜、Chris宅で久々に木星を見ることが出来ました。
日本より20度以上も高く、何かと有利ですが、この日は気流は
悪かった。しかしながら、STrD-2は明瞭と捉えることが出来ま
した。
≪Cebu PHILLIPINES 阿久津富夫≫
|
Robert Heffner (280mm SCT) |
Here is another low altitude image of the STrD-2 side.
Transparency was extremely poor and imaged through fleeting cloud
breaks.
Here is another image with the IR pass filter about 10 minutes earlier.
[Robert Heffner:Aichi,Japan]
The top left image shows the GRS coming into view. White ovals A1,A2 and A3 are visible in the southern hemisphere. The South Equatorial Disturbance is visible along the SEBn near the p. limb. Three NEBs projections lie near the CM and oval WSZ is nestled between the northern edge of the NEB,and the NTrZ.
The lower left image shows the planet 68 minutes later. The GRS is clearly visible. Ovals A4 and A5 have also rotated into view (oval A4 currently lies immediately south of the GRS).
The methane band image shows that oval A2 is methane bright (and therefore probably extends higher up in the Jovian atmosphere) than ovals A1 and A3 which,although being well defined in visible light,are not methane bright. The methane-bright oval A2 has a less well-defined rim than the other southern hemisphere white ovals. Oval WSZ is also methane bright.
[Zac Pujic,Brisbane Australia]
|
Hideo Einaga (250mm Newton) |
[Hideo Einaga Kasai-City Hyogo-Prefecture Japan]
≪兵庫県 加西 永長英夫≫
