木星 ALPO-Japan Latest

Jupiter Image 2011/08/11(UT)
小澤徳仁郎,阿久津富夫,小山田博之,堀川邦昭
Jean-Luc Dauvergne,Christopher Go,Roman Peter Breisch,Sadegh ghomizadeh,Andrea Mistretta,Freddy Willems,Antonio Lasala Garcia,Marc Delcroix
JL Dauvergne,T.Kozawa,Christopher Go,R.P.Breisch,Sadegh.GH,A.Maniero,T.Akutsu,H.Oyamada,F.Willems,A.Lasala,M.Delcroix,K.Horikawa

Jean-Luc Dauvergne(D=356mm SC 1000mm Reflector)
 Date : 2011/08/11 04:42:00 (UT)
Telescope : T1M f/17 Pic du Midi (France)
Camera : Basler acA640-100gm
Seeing : 8/10
Trans : 10/10
Filter : IR 680


Date : 2011/08/11 04:46:00 (UT)
Telescope : T1M f/17 Pic du Midi (France)
Camera : Basler acA640-100gm
Seeing : 8/10
Trans : 10/10
Filter : R-V-B


Date : 2011/08/11 03:21:00 (UT)
Telescope : T1M f/17 Pic du Midi (France)
Camera : Basler acA640-100gm
Seeing : 8/10
Trans : 10/10
Filter : IR 680

2011/08/11 04:52:00 (UT)

Telescope : T1M f/17 Pic du Midi (France)
Camera : Basler acA640-100gm
Seeing : 7/10
Trans : 10/10
Filter : UV
And also a view with the UV filter


2011/10/11 00:40:00 (UT)
Telescope : C14 f/10 Pic du Midi (France)
Camera : Basler aca 640
Seeing : 7/10
Trans : 10/10
Filter : CH4


[Jean-Luc Dauvergne:Paris France]

Kozawa Tokujiro(315mm Newtonian)

(Kozawa Tokujiro : Hachiouji-City Tokyo Japan)
≪小澤徳仁郎:東京都八王子市≫

Christopher Go (355mm SC)
Seeing was excellent.
The STrZ is dark. There is a reddish haze over it. The SEB is dark and complex. Note the dark band south of the SEB.
The NEB is dark. Note the two small red ovals at the CM of the NEB. Will they merge?
Note the reddish feature on the NTBn. The NNTZ LRS can be seen. The reddish ring around it seem to have disappeared. It seems to also have lost it's reddish color. Should this now be called the LWS instead of LRS?

[Christopher Go : Cebu Philippines]
Roman Peter Breisch (285mm SC)
2011/08/11 02:50 UTC
Camera: TIS DMK21AU618
Observation conditions: Seeing 7/10 Transparency  8/10

[Roman Peter Breisch: Munich region Germany]

Sadegh ghomizadeh (235mm SC)



[Sadegh ghomizadeh: Tehran IRAN ]

Andrea Maniero(276mm Dall-Kirkham)
Jupiter in 2011/08/11 morning
Dates  CM  on schedule -

Author :  Andrea Maniero
Location : Padova - Italy
Cassegrain 10" Flea3 CCD
Seeing 6/10 transp 7/10
Coments :
The first session with acceptable seeing very interesting activity in the area and SSTB/ SSTZ,present
very intense  barge in the NEB  area,particularly through green filter.

[ Andrea Maniero Padova ITALY ]

Tomio Akutsu (355mm SC)
雨期の季節、曇りの天気ばかりで晴れる日が少なくなりました。 気流が安定し、SEB内部の複雑な構造が見えます。NNTZのLRSはオレンジ色がなくなりました。

≪Cebu PHILLIPINES  阿久津富夫≫

Hiroyuki Oyamada (200mm VISAC)
DFK21AUの設定を変えて撮影してみました。

≪群馬県  高崎市 小山田博之≫
[Hiroyuki Oyamada : Takasaki Gumma Japan]

Freddy Willems(356mm SC)
Seeing was terrible so I only post the IR captures. The RGB looks terrible.





[ Freddy Willems :Hawaii U.S.A]

Antonio Lasala (254mm Newtonian)
Date Time: 2011/08/11 03:28:44 (UT)
254  Newtoniam
Camera: Basler acA640-100gm



[Antonio Lasala :Morata de Jalon:Spain]

Marc Delcroix (254mm SC)
Some details can be seen inside the GRS,and following it in the SEB there are some eruptive bright spots (one can be made out in the methane image) which are recent (not present a few days before). In methane image,again only the preceding south part of the SEB is dark.

The aspect of the STB is extremely interesting,it looks like the preceding section preceding would be linked to the GRS,and the following section is spread out in latitude in the zone.
The longest of the two barges in the NEB as a clear spot inside,and two small spots are visible in the north polar area in the methane image.









[Marc Delcroix  Tournefeuille,France]

Kuniaki Horikawa

≪神奈川県横浜市泉区  堀川邦昭≫[Kuniaki Horikawa:Kanagawa Japan]
