木星 ALPO-Japan Latest

Jupiter Image 2012/08/24(UT)
橋野英嗣,米山誠一,三品利郎,内藤峰夫,長谷部孝男,青木和夫,柚木健吉,畑中明利,吉田知之,小澤徳仁郎,阿久津富夫,岩政隆一,大友武彦,永長英夫,堀川邦昭
Antonio Lasala Garcia,Michel Jacquesson,Javier Beltran Jovani,Christopher Go,Gary Walker,Donald C Parker,Andrea Mistretta,Clif Ashcraft,Paulo Casquinha
A.Lasala,Michel.J,Javier,H.Hashino,S.Yoneyama,T.Mishina,M.Naitou,Christopher Go,T.Hasebe,G.Walker,K.Aoki,Don,K.Yunoki,A.Hatanaka,T.Yoshida,T.Kozawa,A.Mistretta,T.Akutsu,R.Iwamasa,C.Ashcraft,T.Ootomo,H.Einaga,K.Horikawa,P.Casquinha

Antonio Lasala (254mm Newtonian)


[Antonio Lasala :Morata de Jalon:Spain]

Michel Jacquesson (203mm SC)

[Michel Jacquesson : Sevigny-Waleppe (Ardennes) France]

Javier Beltran Jovani(356mm SC )











[Javier Beltran Jovani:Castellon-Spain]

Hidetugu Hashino(305mm Newtonian)

≪千葉県木更津市 橋野英嗣≫[Hidetugu Hashino:Chiba:Japan]

Seiichi Yoneyama(248mm Newton)

≪神奈川県横浜市  米山誠一≫[Seiichi Yoneyama:Kanagawa Japan]

Toshirou.Mishina (200mm Newtonian)

≪神奈川県  横浜市  三品利郎≫[Toshirou.Mishina:Kanagawa Japan]

Mineo Naitou(280mm SC)

[内藤峰夫:千葉県 流山市][M.Naitou:Chiba Japan]

Christopher Go (355mm SC)

Conditions were excellent this morning. The sky cleared just after I woke up.
The NEB continues to be very complex. There are complex rifts associated with the EZ feestons on the NEB.
The SEB also looks disturbed. Note the bright spot on the mid-SEB.
This feature is prominent in the IR image below. Is this the South Equatorial Disturbance (SED)?




[Christopher Go : Cebu Philippines]
Takao Hasebe (280mm SC)


[T.Hasebe Kasugai Aichi JAPAN]
≪愛知県春日井市  長谷部孝男≫

Gary Walker(254mm APM)

[Gary Walker:Georgia:USA]

Kazuo Aoki(280mm SC)
今朝の木星です。
場所の制約から昇り始めの30度までが限界です。
今日はシーイングが比較的良くて何とか絵になりました


[青木和夫:東京都世田谷区][Kazuo Aoki:Tokyo Japan]

Donald C Parker(16-in (356mm SC) Newtonian)
I have attached some RGB and CH4 Jupiter images from 24 August
showing the planet occulting Ganymede.






[ Donald C Parker Coral Gables,Florida U.S.A]

Kenkichi.Yunoki (260mm Newtonian)


[Kenkichi Yunoki (Sakai City Japan)]
≪大阪府 堺市 柚木健吉≫
Akitoshi Hatanaka (400mm Cassegrain)

≪三重県熊野市  畑中明利≫[Akitoshi Hatanaka:Kumano Mie Japan]

Tomoyuki Yoshida(300mm Dall-kirkham)

[吉田知之 Tomoyuki Yoshida:Utsunomiya,Tochigi,Japan]

Kozawa Tokujiro(318mm Newtonian)

(Kozawa Tokujiro : Hachiouji-City Tokyo Japan)
≪小澤徳仁郎:東京都八王子市≫

Andrea Mistretta(80mm ED)

[Andrea Mistretta:Cagliara - Italy]

Tomio Akutsu (355mm SC)


≪Cebu PHILLIPINES  阿久津富夫≫

Ryuichi Iwamasa(356mm SC)

≪神奈川県横浜市  岩政隆一  ≫[Ryuichi Iwamasa:Kanagawa:Japan]

Clif Ashcraft(184mm Schupmann)
Attached is an image of Jupiter taken with the GigE Flea3 color camera coupled to the 7.25" Schupmann medial with a 2x shorty Barlow lens.
The combination gives an effective focal ratio of f/32. .
Seven videos were taken using Firecapture software.
They were debayered as captured using the HQLinear algorithm.
The videos were then preprocessed with PIPP to center the planet in a 450x450 pixel frame and the frames sorted by quality,
saving out only the best 1200 frames as a new video file.
The new files were then processed with Registax 6,
aligning and stacking all 1200 frames from each video to give seven wavelet
sharpened images spanning the time between 09:14:44 UT and 09:245:46 UT on the morning of August 23, 2012.
The program WinJUPOS was then used to derotate all eleven images to the time of 09:20.0 UT and stack them.
The final attached image was sharpened again using wavelets in Registax6.
The blur below and to the left of the planet is the satellite Ganymede which moved considerably during the time the seven videos were taken.
Seeing during the video capture was slightly above average (6/10) and transparency was good (7/10).
[Clif Ashcraft:New Jersey:USA]

Takehiko.Ootomo(280mm SC)

≪宮城県仙台市  大友武彦≫[T.Ootomo Sendai-City Miyagi Japan]

Hideo Einaga (300mm Newton)

[Hideo Einaga Kasai-City Hyogo-Prefecture Japan]
≪兵庫県  加西  永長英夫≫

Kuniaki Horikawa(300mm Newtonian)





≪神奈川県横浜市泉区 堀川邦昭≫[Kuniaki Horikawa:Kanagawa Japan]
Paulo Casquinha (C14 355mmSC)


[Paulo Casquinha Palmela,Portugal]
