Jupiter Image 2014/11/17(UT)
xb
Trevor Barry,Bruce Macdonald
K.Horii,T.Barry,B.Macdonald

Keisaku Horii (305mm Newton)

ᕺɌPHs  xb[Keisaku Horii : Himeji Hyougo Japan]

Trevor Barry(406mm Newtonian)
Imaged Jupiter this morning,Nov 17th in reasonable seeing for the lowish alt.
Have 5 742nm IR data set over a 68 minute session along with 2 R channel data sets 20 minutes apart and 1 RGB. I note 2 small white ovals in the STZ visible in IR,R & RGB.
There is a shadow transit of Europa in all data sets bar the first IR.
There are some quite extravagant festoons in the EZ. I note a particularly interesting feature that extends into both the NEB & NTrZ.
In RGB it is a large pinkish spot,it is well seen in the R channel and structure can be detected in the IR,
it looks somewhat like a Northern version of the GRS. This is quite apparent in the animation of all 5 IR data sets. I also note a small bright spot down in the NTZ with an even smaller bright spot down on the Southern edge of the NPR.
The NPR related spot is seen in IR,R & RGB data sets,j2014-11-17_17-59_ir_tba,j2014-11-17_18-13_ir_tba,j2014-11-17_18-54_r_tba & j2014-11-17_18-11-54_rgb_tba. These spot are also well seen in the IR animation.
[Trevor Barry:Broken Hill:Australia]

Bruce Macdonald(355mm SC)

(Bruce Macdonald : Punta Gorda,Florida USA)
