Jupiter Image 2017/07/09(UT)
石橋力,大田 聡
Trevor Barry,Javier Beltran Jovani,Clyde Foster,Jose Alberto Berdejo,Pericles Enache,Manos Kardasis
T.Barry,T.Ishibashi,Javier,S.Ota,C.Foster,A.Berdejo,P.Enache,Kardasis
Imaged Jupiter July 9th in abysmal seeing but as it was my final opportunity to capture the GRS prior to JUNO's Perijove 7 I have attached the results from the session.
[Trevor Barry:Broken Hill:Australia]
そこそこの写りですが、この後薄雲が徐々に出た感じで、1枚だけです。
イオが木星面経過を始めました
NEBはのっぺりとした感じです。
(Tutomu-Ishibashi Kanagawa-P Japan)
≪神奈川県 相模原市 石橋力≫
[Javier Beltran Jovani:Castellon-Spain]
[Tomigusuku city Okinawa Japan]
≪沖縄県 豊見城市 大田 聡≫
RGB from yesterday evening.
Oval BA at lower right,STB Ghost approaching CM,as is the TSZ-2 oval on the northern edge of the NEB.
TSZ-1 approaching the p limb. The light spot and red barge in the centre of the SEB is still evident.
Busy with processing images a bit later in the evening that hopefully will give a decent view of the GRS and PJ7 track,although seeing conditions were deteriorating.
I tried my hand at aligning Ganymede,which was just about to go into transit
If I have it correct(open to correction),the captures are approx. 28h prior to flyby of Juno on PJ7.
I have boxed and exploded the north and south regions of the flyby where I believe most of the Points of Interest(POI’s) are located.
I have also included an exploded R view of the GRS.
The dark mark in the NPR(right of the box) is Ganymede which was in transit,and any detail around it should be considered with caution due to derotation.
I have another,later,dataset from yesterday evening which I will try and process,although the seeing was deteriorating quite badly later in the evening.
I have one more opportunity this afternoon at about 17.00 local time,so it will be twilight conditions.
Forecast is clear,although a strong jetstream is also projected(as with last night). However,I will try my best to get some data.
[Clyde Foster:Centurion,South Africa]
[Jose Alberto Berdejo:Zaragoza Spain]
[Pericles Enache,Sao Paulo,Brazil]
[Manos Kardasis,Glyfada-Athens;Greece]
《カーダシス マノス:ギリシャ アテネ》
