Saturn Image 2003/11/15(UT)

Ed Grafton,Rolando Chavez

E.Grafton,rolochavez


Ed Grafton (14 inch f/11 Celestron SCT, ST6 CCD medium resolution mode)
Hi Saturn Observers
Here is an observation from November 15th 2003. The sky was mostly cloudy
but there was a window when it was clear so I got what I could of the
occultation event. The transparency was good 7/10, and seeing was fair to
good to 6/10. Light 4mph SE wind and heavy dew. The weather was mild with
the temperatures in upper 60s F.

Ed Grafton, Houston Texas, ST5C CCD and a 14 inch f/11 Celestron SCT
Barlow Projection to f/27 aprox .21 arc seconds per pixel.
Image data:
BLUE    + IR rejection, 1  second, Edmunds filter
GREEN   + IR rejection, .8  seconds, Edmunds filter
RED     + IR rejection,  .6  seconds, Edmunds filter
Clear filter,  No IR  .3  seconds,  Edmunds filter
[Ed Grafton, Houston Texas U.S.A.]

Rolando Chavez(200mm Newtonian Philips toUcam)
I took these images with a 20cm f/7 Newtonian and a Philips toUcam.
I had an opening in the clouds for a short time and I was able to capture some images of this rare event.
[Rolando Chavez  Springs, GA USA]
