火星 月惑星研究会 関西支部

Mars Image 2005/08/29(UT)
米山誠一,柚木健吉,永長英夫,瀧本郁夫,新井 優,畑中明利,鈴木 隆,福井英人,
Martin Mobberley,Ralf Vandebergh,David M Moore,Christophe Pellier,Bruno Daversin,Jan Adelaar,Damian Peach
S.Yoneyama,K.Yunoki,H.Einaga,I.Takimoto,M.Arai,A.Hatanaka,T.Suzuki,H.Fukui,M.Mobberley,R.Vandebergh,D.Moore,Christophe.P,B.Daversin,J.Adelaar,D.Peach

解説(安達)
  全体の傾向は、ここ数日と変化はない。ヘラス(Hellas:290W,-50)は夕方のエ
ッジの中で明るさを保っている。北極雲は、全体が拡散傾向だ。ここ数日の間
に低い緯度に雲が見えるようになった。今日は、目立った変化はない。
(reported by 14 observers)

The entire tendency has here neither several days nor changes.
Hellas (290W,-50) keeps brightness on the edge in the evening. In an
Arctic cloud, the whole is a diffusion tendency. The cloud came to seen
low latitude in these several days. There is no remarkable change today.
(reported by 14 observers)
FROM Makoto ADACHI
-------------------------------------------------------------------------------------

Seiichi Yoneyama(200mm F4 Newton,ToUcam PRO)
≪神奈川県横浜市  米山誠一≫


Kenkichi.Yunoki (200mm Newtonian, ToUcam Pro)
雲が厚く覆い今夜は無理と考えていたが、2時30分頃から雲が切れてきた。CM=327〜331の画像の欠け際、イアピュギア辺りに小さな突起状の盛り上がりがある。
アキダリアを覆っている極雲は昨日のCM=346と比較すると、南部に拡散していっているように見える。
モニター上でクリュセが昨日より明るく見えた。


27日から29日までの同一経度の火星面の比較です。
アキダリアの極雲の動きと濃淡の変化が判ります。マルガリティフェルからクリュセ辺りにかけても薄い雲があるようにも思えます。また、ノアキスからアルギュレ辺りも少しずつ地面の模様が出てきているような感じもしますが、処理が安定しないので断定は出来ません。


火星08月27-29日のCM340°付近の変化についての比較動画をつくってみました。

[Kenkichi Yunoki (Sakai City Japan)]
≪大阪府 堺市 柚木健吉≫
Hideo Einaga (250mm Newton, Toucam Pro Webcam)
[Hideo Einaga Kasai-City Hyogo-Prefecture Japan]
≪兵庫県  加西  永長英夫≫


Ikuo Takimoto (310mm Newtonian :ToUcam Pro )
コメント:やはり、ミッチェル山は見えなくなっていた。
撮影開始時はそこそこのシーイングであったが、
雲が出てきて、20時前には雲に覆われました。
アキダリウム(MARE ACIDALIUM)には朝霧が出ている
ようで、青白く輝いている。

火星とその観測(佐伯恒夫著)恒星社厚生閣の105頁
には、以下の記述があったので、記述しておきます。

火星像の西端から現れるとき(つまり日の出の頃)
には、必ず真白い雲や霧に包まれて淡く見えているが
夜明け後、次第に雲が淡化して行き、海は濃度を増加
させ、子午線通過の頃(正午の頃)には、完全に黒っ
ぽい姿を現わしてしまう。ただし、夕暮れ時には、奇妙
なことに、雲を被ることもなく、真黒い姿のまま火星像
の東縁に没して行くことが多い(ごく希に夕雲におおわ
れることもあるが)とある。
[Ayauta-gun Kagawa-Prefecture Japan]
≪香川県  綾歌郡  瀧本郁夫≫


Masaru Arai (280mmSMC Newton, Philips ToUcam Pro PCVC740K)
280mm SCT,2×エクステンダー(150%リサイズ)
Philips ToUcam Pro, 1/25 sec
900 frames composite
Seeing:5/10 Transp.:2/5
[Masaru Arai Yorii-machi  Saitama-Prefecture  Japan]
≪埼玉県寄居町  新井 優≫


Akitoshi Hatanaka (400mm Cassegrain, ToUcam Pro)
  40cm Cassegrain(F15)  +  Vari-Extender (f=10700mm)
1 degree Prisum  IR block Filter  FUJI  IR76
Philips ToUcam Pro  Rezistax 3   seeing  3/10 trans 3-4/10

天候が落ちそうなので、12時から撮影を始めた。
雲の合間から5カット撮影した。
1:30には、完全に雲の隠れた。
1:00頃になって、像が安定してきたと思ったら、
雲に入ってしまった。
≪三重県熊野市  畑中明利≫


Takashi Suzuki (180mmMakustov Casegrain, ToUcam Pro)
コメント:透明度が悪く、時折薄雲が通過しましたが、シーイングが良く、
白く輝く小さな南極冠、サバ人の湾、青白い北極雲がx450で良く見えました。


[Takashi  Suzuki  (Hachiouji-City Tokyo  Japan)]
≪東京都八王子市  鈴木  隆≫


Hideto Fukui (250mm Dall Kirkham, Philips ToUcam Pro)

[Hideto.Fukui (Shizuoka-Prefecture Japan)]
≪静岡県藤枝市 福井英人≫
Martin Mobberley (245mm Newton: Lumenera LU 075M)
my first with a new Lumenera LU 075M USB 2.0 camera.
F-ratio was increased to 48 to compensate for the larger 7.4
micron pixels. Seeing was very poor, of the fast 'juddering'
variety. A trial frame rate of 30 fps was tried which seemed
to freeze a fair amount of detail in the very poor conditions.
.
Orion Optics 245mm f/6.3 Newt + 5x Powermate = f/48.
Lumenera LU 075M + Red & Blue filters.
Transparency good. Temp + 12 C.  No Dew !?

Captured/converted with Streampix/Virtual Dub.
Processed with Registax 3/Maxim DL/PSPro 8.
Further details on the image.

I am now adopting the preferred BAA Mars Sec. file name
structure for my Mars images.

Regards
Martin Mobberley

P.S. I am updating my Mars web pages with my best (not many!)
2005 images on a fairly regular basis:

[Martin Mobberley: United Kingdom]


Ralf Vandebergh(250mm Newton:ATK-1HS)
Attached is the complete observation-set of my Aug 29 session;
Olympus Mons shows incredible detail
with different ringstructures.
Again the 2 blue images of the animation are added below.


Here is an especially natural image,later in my Aug 29 Mars observing session.This might be the best image
I took so far,concerning visuall impressions.
10 inch Newton & ATK-1HS with color filters f/62


It is interesting to see how the shadow of Olympus Mons becomes visible when it turns to the terminator.
See it in my animation made of images from my Aug 29 observing session.

[バンディバ:オランダ]
[Ralf Vandebergh:Neighbourhood of Maastricht Netherlands]

David M. Moore(25cm Newtonian, Philips ToUcam)
Seeing quite variable this morning, but far better than the past few days. I imaged Friday and Saturday and only could find 27 useable images out of 1200!!
Hellas bright in the morning. South Pole hazes.

[ David M Moore Phoenix, Arizona U.S.A]
Christophe Pellier (C14 ; Lumenera ATK-1HS)
Seeing was far as good as expected away from the jetstream but the Lumenera did survived well, much better than the webcams I have tried also that night... especially, the SNR is really good. The L frame has been shot in 12 bits and 20 % gain only (all images are in 12 bits)

[Christophe Pellier Bruz City , France]
Bruno Daversin (200 mm Mak_cas:ATIK)
[Bruno Daversin  Cherbourg, France]

Jan Adelaar(178mm (7') Maksutov cass:ToUcam)
Here a capture of 29th of august with fair conditions. Olympus Mons is visible as some Arcasia domes groeten Jan Adelaar

[ジャン-アデラー:オランダ]
[Jan Adelaar:Arnhem City Netherlands]
Damian Peach (235mm Celestron SCT:Lumenera LU075)
Here are some images from August 29th. Fair to good seeing. Lots of interesting features are seen similar to the previous session. The Arsia cloud notably brightens as it approachs the evening limb. Also note all of the Tharsis volcanoes can be seen in Red and colour images - all appear decidedly redish, especially Olympus and Ascraeus Mons.



14" (35cm) Celestron SCT @ f/39.5. Lumenera LU075M CCD camera.  Seeing again initially fair (p4-5) later good (p6-8.)
Transparency excellent (5,5mag.) No wind. Moderate dew.   Alt=44-52 degs.
[Damian Peach: Loudwater, Buckinghamshire, United Kingdom]
