木星 月惑星研究会 関西支部
Jupiter Image 2006/06/09(UT)
中井健二,畑中明利,瀧本郁夫,福井英人,永長英夫,冨田安明
Fattinnanzi Cristia,Christopher Go,Tiziano Olivetti,Christophe Pellier,Paolo Baldoni,Ralf Vandebergh,David M Moore,Cristina Cellini
K.Nakai,A.Hatanaka,I.Takimoto,C.Fattinnanzi,H.Fukui,H.Einaga,Christopher Go,T.Olivetti,Y.Tomita,Christophe.P,Baldoni,R.Vandebergh,D.Moore,C.Cellini
|
Kenji Nakai( LX200-25(254mmF10SC),ToUcam Pro) |
2006/06/09 13:00:51(UT) I:102.7 II:140.6 III:289.1
LX200GPS-25(254mm Schmidt Cassegrain f/10)
pentaprism+LE12.5mm+IR-cut+ToUcam Pro II(fl:4200mm)
exp.:1/25sec. 15fps 60sec.
seeing:3-5/10 transp.:1-3/10
comment:
薄雲が通過する。ノイズが多く、眼視の方がよく見えている。
GRSの中の目玉は眼視ではオレンジ色。BAは眼視では色がよく
分からない。
≪広島市 中井健二≫
|
Akitoshi Hatanaka (400mm Cassegrain,Lu075C) |
seeing 悪い
ややゆっくりした大きなユレで木星のＤＩＳＣがゆれていた。
≪三重県熊野市 畑中明利≫
|
Ikuo Takimoto (310mm Newtonian :ToUcam Pro ) |
コメント：だいぶ永続白斑ＢＡがＧＳＲに近づいた。
ＳＴｒＺが明るいと感じた。ＧＲＳ後方のＳＴｒＺに、暗斑
が２個見える。うす雲が通過するたびに、ゲインコントロール
を行いながら撮影せざるを得なかった。でも、撮影できただけ由
とする。全体的には、ＳＥＢが細くなったように見える。
展開図も作成してみた。
[Ayauta-gun Kagawa-Prefecture Japan]
≪香川県 綾歌郡 瀧本郁夫≫
|
Fattinnanzi Cristian ( 250mm Newtonian Philips Vesta Pro) |
[Fattinnanzi Cristian : Macerata ITALY]
|
Hideto Fukui (250mm Dall Kirkham,Philips ToUcam Pro) |
[Hideto.Fukui (Shizuoka-Prefecture Japan)]
≪静岡県藤枝市 福井英人≫
|
Hideo Einaga (250mm Newton,Lu075C) |
このところ透明度が悪く、報告に十分な画像が得られていませんので、ほとんど没にしています。
海外の方々の精細な画像を見ていると、観測条件の悪い日は無駄足に終わるので、体力温存に徹しています。
・BA（Ⅱ＝131.2）がGRS（Ⅱ＝113.7）南部を通過し始めました。
・GRS後方のSEBに２本の大きな暗中もどきがあり、とても気になります。これはmid-SEB outbreak の先端と
見ていいのでしょうか？
・STｒZ Ⅱ＝149.4 と 157.1 に暗斑があり、GRSに近づいています。
[Hideo Einaga Kasai-City Hyogo-Prefecture Japan]
≪兵庫県 加西 永長英夫≫
|
Christopher Go (Celestron C11,DMK21BF04 monochrome camera) |
Here's my latest image of Jupiter. Conditions were terrible because of clouds. Transparency was very poor with seeing only at 6-7/10. Both red spots are really moving closer now. It's 4-5 weeks before conjunction and already the area above the GRS and to the left of the BA is distorted.
Also the red NNTB barge that John Roger's predicted to fade is really fading now!!!
[Christopher Go : Cebu Philippines]
|
Tiziano Olivetti((275mm Newtonian:Lumenera LU075M) |
here attached few images of Jupiter at different wavelenghts taken last Friday.
Seeing was average and transparency poor,but it's interesting to notice the converging of the 2 ovals in the NEB at L2=220.
［ティジャノ:オリベッティ タイ バンコク］
[Tiziano Olivetti : Bangkok Metropolis : Thailand]
|
Yasuaki Tomita (255mmREF,Bitran 32L CCD Camera) |
とうとう梅雨に入ってしまいました
５月６月の観測日数はわずか数日です
薄雲を通しての撮影です。
≪群馬県佐波郡 冨田安明≫
|
Christophe Pellier (C14 ; L075M) |
Hi guys,finally the seeing degraded. I can't say that this happened quite often recently in my location !
Interesting is nonetheless the thick EB/EZs part,almost the darkest part of the planet in near-IR.
This illustrates how weak can be the explanation of seeing by the jetstream ; it was extremely weak that night,no more than 4 meters .sec ; it was running some 10 times faster for my best images of june 2nd.
I'm used to explain this poor seeing by the presence of a moderate (though) easterly ground wind. Even a a fast jetstream,if coming from the north or west,doesn't degrade the image that much.
Best wishes
[Christophe Pellier Bruz City,France]
|
Paolo Baldoni (261mm Newtonian :Lumenera Lu075 ) |
2006/06/09 19.54 (UT)
Newton LBF 261mm
Barlow 5x
Lumenera LU075M
(E44d25'37",N08d56'00")
[Paolo Baldoni Genova,North Italy]
|
Ralf Vandebergh(250mm Newton:ATK-1HS) |
This is an image of Jupiter obtained on June 9 in fair seeing considering the altitude.
The GRS whows a nice inner ring(actually spiral structure as it would be resolved at
higher resolution).
This is a monochrome version of the 22:49 UTC observation.Note the dark spot at the inner southern edge of the GRS
as a pupil in the eye of Jupiter...)
10 inch Newtonian & ATK-1HS camera)
[バンディバ:オランダ]
[Ralf Vandebergh:Neighbourhood of Maastricht Netherlands]
|
David M. Moore(250mm Dall-Kirkham Cassegrain:ATK camera) |
[ David M Moore Phoenix,Arizona U.S.A]
|
Cristina Cellini(Meade LX200 12":Lumenera Lu075C) |
2006/06/09 19.52 (UT)
Meade LX200 12"
Lumenera Lu75C
Barlow Abbe Baader-Zeiss 3x
[Cristina Cellini:Ravenna Italy]
