Jupiter Image 2008/06/11(UT)
Damian Peach,Sadegh ghomizadeh,Antonello Medugno,David Arditti
D.Peach,Sadegh.GH,A.Medugno,D.Arditti
|
Damian Peach (350mm Celestron SCT) |
Thought i'd at least have a go from here to see what was possible. RGB,IR and CH4 images attached. Altitude was 14-16o. The mid-seb outbreak longitude was presented.
[Damian Peach: Loudwater,Buckinghamshire,United Kingdom]
|
Sadegh ghomizadeh (280mm SC) |
information: telescope Celestron 11" Schmidt Cassegrain Focal lenght 2800 mm,focal ratio 10,camera SKYnyx mono+2xBarlow+60mm filter wheel f 37,30fps total 1200 frames stacks
Filter: astronomik RGB,processing software: regitax & PS At 30 Degrees the Horizon. very poor seeing
information: telescope Celestron 11" Schmidt Cassegrain Focal lenght 2800 mm,focal ratio 10,camera SKYnyx mono+2xBarlow+60mm filter wheel f 37,30fps total 1200 frames stacks
Filter: astronomik RGB,processing software: regitax & PS At 30 Degrees the Horizon. very poor seeing
[Sadegh ghomizadeh: Tehran IRAN ]
|
Antonello Medugno (356mm SC) |
2008/06/11 - RGB UT: 01:09.1 - Irpass: 01:26.4
Meade 14" LX200 GPS, efl= 6400 mm
Filters: RGBset and IRpass pro (Astronomik)
Camera: ImagingSource DMK 21AF04.AS @ 33ms (Irpass 66ms)
Seeing 5,5/10, Trans.: 3/5
Comments: I used R+Ir instead of R-Ir for R channel
[Antonello Medugno,Capua-Italy]
More false-colour imaging using IR, with good seeing for the altitude. Surprisingly delicate detail visible in the EqZ and SEB.
These additional images from the 11th were taken at a lower focal ratio than those I sent yesterday, so as to get a sufficient intensity on the chip to image at 807nm.
Still, the experiment shows, that even about f12, the results are better from the 742nm filter. The 807 works in a range where sensitivity is not so high, and the required longer exposure length seems to more than make up for being further into the IR. In fact, the only objects for which I have found 807nm useful are Venus, the Sun and the Moon.
[David Arditti: Edgware Middlesex HA8 5LW: United Kingdom]
