y ALPO-Japan Latest

Saturn Image 2020/06/10(UT)

Jean-Luc Dauvergne,Efrain Morales Rivera,Trevor Barry
JL Dauvergne,E.Morales,T.Barry

Jean-Luc Dauvergne

[Jean-Luc Dauvergne:Paris France]

Efrain Morales Rivera

[Efrain Morales Rivera  Aguadilla:Puerto Rico]

Trevor Barry
In good seeing. The 685nm IR data well resolves the North Polar vortex with the vertices of the polar hexagon very well defined. Concentric rings of structure are resolved in the North polar collar. There is a bright spot on the edge of the hexagon at approx Lat+77.5 L3 87.6 there is also a bright spot resolved at approx Lat+30.6 L3 152.9. At least two ripples are also resolved on the edge of the EZ impinging into the NEB, The R channel data also resolves the structure within the North polar collar along with the ripples on the edge of the EZ.




[Trevor Barry:Broken Hill:Australia]
